In the intro of my app, about 40 fish swim from right to left. When you tap or swipe across the screen, they react: they speed up and the entire school changes rhythm. The fun part? I didnβt animate their movement with keyframes, but literally drew it with my finger on the screen.
From Finger Movement to Fish Paths
While prototyping, I wanted the animation to feel human and playful. So I built a system that recorded my finger movement and turned it into paths:
- I swiped my finger across the screen; the app stored the x and y coordinates per frame.
- These coordinates were converted into a route (polyline/spline) for the fish.
- Each time the app started, the fish followed these paths β as if they were chasing my hand.
Interaction: Swimming Faster on Touch
The fish react to touch events. If you tap a fish (or the water), the app temporarily increases their speed and sometimes changes the density of the school. This made the intro feel lively and responsive.
Technical Details (Objective-C)
The snippet below shows how I recorded touch points and generated a path that each fish could follow. (Simplified for readability.)
// Touch recording (UIView / Scene overlay)
@property (nonatomic, strong) NSMutableArray<NSValue *> *touchPoints;
- (void)touchesMoved:(NSSet<UITouch *> *)touches withEvent:(UIEvent *)event {
UITouch *t = [touches anyObject];
CGPoint p = [t locationInView:self.view];
if (!self.touchPoints) self.touchPoints = [NSMutableArray array];
[self.touchPoints addObject:[NSValue valueWithCGPoint:p]];
}
// Generate path (simplified) and assign to fish
- (UIBezierPath *)pathFromTouchPoints {
UIBezierPath *path = [UIBezierPath bezierPath];
if (self.touchPoints.count == 0) return path;
CGPoint start = [self.touchPoints.firstObject CGPointValue];
[path moveToPoint:start];
for (NSValue *v in self.touchPoints) {
[path addLineToPoint:[v CGPointValue]];
}
return path;
}
// Each fish gets an offset on the same base path for variation
- (void)assignPathToFish:(FishSprite *)fish basePath:(UIBezierPath *)path offset:(CGFloat)offset {
// offset translates the path slightly in y-direction or via timing shifts
fish.motionPath = [path copy];
fish.pathOffset = offset;
}
Why This Works for the Experience
- Natural rhythm: hand-drawn paths have micro-variations that feel βalive.β
- Immediate feedback: touch = speed up. Kids and adults understood it instantly.
- Tech supports emotion: code makes the magic possible, but the experience is what matters.
The Lesson I Took Away
Not every animation needs to come from a tool or keyframe editor. Sometimes a tactile approach β recording movement with your finger β gives exactly that organic feel thatβs hard to simulate with pure code. Combining touch recording, path generation, and real-time interaction turned a simple intro into a playful, magical moment.
